Case Of the Month

Diagnosing a Shunt on Sonogram

An 8-year-old FS Maltese was presented for evaluation for severely elevated pre and post-prandial bile acids and mild ALT elevations and subnormal BUN. In addition, the patient was positive for Rocky Mountain spotted fever. Seizure activity was present in the history.

DX

Spleno-azygos shunt with chronic inflammatory hepatopathy.

Outcome

The patient is currently stable on medical management alone and no further seizure activity or other clinical signs have been noted.

Comments

Given the low BUN in this patient there was concern about emerging liver failure especially given the patient’s age. It was debatable whether surgical intervention with ameroid constrictor would be the optimal approach as the liver may not have been able to handle the new volume owing to chronic disease and potential for concurrent portal vein hypoplasia. Cystotomy would also be recommended at the time of surgery. Dietary management with Royal Canin hepatic support, high quality adjunct with a minor amount of yogurt or cheddar cheese was also be considered. Lactulose was suggested long term and Metronidazole was recommended for 14 days with nutraceuticals following the scan. Alternatively, a surgical consultation is recommended. If surgical intervention is to be performed, which was the primary recommendation in this case, the surgeon must be prepared for the potential of the onset of portal hypertension at the time of surgery post ameroid placement.

Ideally US-guided lievr biopsy would be performed if only medical approach is taken in order to potetnially refine thereapy based on the presence of concurrent disease.

Special thanks to Seth Mitchell, DVM of Mobile Veterinary Imaging of SE Florida (http://www.mobileveterinaryimaging.net/meet-our-team.html) for his submission of this case and continually utilizing the remote consultation & support services of SonoPath.com. We would also like to thank Dr. Stengard at the Vero Beach Veterinary hospital.

Clinical Differential Diagnosis

Porto-caval shunt, primary portal vein hypoplasia, hepatic fibrosis, liver cirrhosis. Primary CNS disease: inflammatory/infectious, neoplasia, GME.

Sonographic Differential Diagnosis

Spleno-azygos shunt with concurrent chronic inflammatory hepatopathy. Small right calculi were noted in the bladder measuring 0.1 and 0.2 cm each.

Image Interpretation

The urinary bladder presented a small concretion that measured 0.5 cm and was non-shadowing. The kidneys presented a significant amount of pelvic mineralization that was non obstructive. The left kidney measured 3.6 cm. Calculus was noted in the left kidney pelvis and measured 1.16 cm. The right kidney measured 4.24 cm with pelvic calculus that measured 1.49 cm. The liver was subnormal in size with coarse architecture and increased portal markings. The vena cava measured 0.74 cm, aorta 0.62 cm. The portal vein was subnormal in size and measured 0.29 cm. An extrahepatic, portosystemic shunt was noted. This was deriving from the splenic vein entrance into the portal vein. This was tortuous and measured approximately 0.5 cm in width and traveled dorsally and entered into the aortic hiatus. This created a splenoazygos shunt and a “double aorta” was formed. Concurrent hepatic disease is likely given the increased portal markings and remodeling.
